1. Q: Do you have after sales support?
 A: Yes, we are happy to give advice and we also have skilled technicians available, We need your machines running in order to keep your business running.
Â
2. Q: Once we've bought a machine from you, are you able to supply us with material?
 A: We can assist you in finding the appropriate materials to suit your machine
Â
3. Q: Do you sell only standard machines?
 A: No, most of our machines are built according to customers specifications, using top brand name components.OEM is acceptable
Â
4. Q: Do you have a warranty on your machines?
 A: One year warranty excluding electrical components.
Â
5. Q: What sales terms do you have?
 A: T/T, L/C,West Union.
Â
6. Q: Do you have instruction manuals?
 A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings or Video Support,
Â
 7. Q: What is your delivery time?
 A: Depending on the type of machine, duration of 10 days to 45 days from date of order.Â
I. Main Features for Horizontal Flat Bed CNC Lathe
1. Construction casting molded
2. Turcite-B coated on mating surfaces between saddle and guideways Â
3. Precision ballscrew,high rigidity precision compound bearings ,centralized oil lubricator
4. High spindle speed
5. Flexible control panel
6. Popular full enclosed guards
7. Vertical toolpost,horizontal toolpost,quick change toolpost,etc
8. Optional,pneumatic,hydraulic chuck and tailstock
9. FANUC,SIEMENS, GSK,etc.
II . Main Technical Specifications of CNC Lathe
Â
| Parameter | Unit | CKNC6136 | CK6136A | CK6140 | CKNC6150A |
| Max.swing over bed | mm | 360 | 360 | 400 | 500 |
| Max.swing over slide | mm | 200 | 200 | 230 | 300 |
| Max. processing length | mm | 750/1000 | 500 | 750/1000 | 1000 |
| Guideway Width of bed | mm | 280 | 350 | 350 | 390 |
| X axis travel | mm | 210 | 210 | 220 | 250+10 |
| Z axis travel | mm | 750 /1000 | 750 | 750 | 750,1000,1500,2000 |
| X/Z axis lead screw | Â | 2505/3206 | 2505/3206 | 2505/3206 | 2505/4010 |
| X/Z axis rapid speed | m/min | 6/8 | 6/8 | 6/8 | 6/8 |
| X/Z positioning precision | mm | 0.02/0.03 | 0.02/0.03 | 0.02/0.03 | 0.02/0.03 |
| X/Z repositioning precision | mm | 0.012/0.016 | 0.012/0.016 | 0.012/0.016 | 0.012/0.016 |
| Processing precision | Â | IT6-IT7 | |||
| ellipticity | Â | 0.01 | |||
| Surface roughness |  | Ra≤1.6 | |||
| Spindle speed range | Â | Two steps, 80-400-2000 | 50-3500 | 50-3500 | 60-200,200-650,650-1600 |
| Spindle head type | Â | ISO A2-6/D6 | A2-6 | A2-6 | c-5, c-8,D-8 |
| Dia. Of spindle thru- hole | mm | 52 | 56 | 66 | 82, 105 |
| Spindle hole tapper | mm | MT6 | MT6 | MT6 | 105mm, 1:20 |
| chunk | mm | 200(8") | 200(8") | 200(8") | 250 |
| Spindle Motor power | kw | 5.5 | 5.5 | 5.5 | 7.5(three steps frequency) |
| Tool holder type | Â | Vertical 4 stations, horizontal 6 stations | |||
| Turning tool size | mm | 25*25 | 25*25 | 25*25 | 25*25 |
| Tailstock sleeve travel | mm | 100 | 120 | 120 | 150 |
| Tailstock sleeve dia. | mm | 52 | 60 | 60 | 75 |
| Tailstock sleeve taper | mm | MT4 | MT4 | MT4 | MT5 |
| controller | Â | SIEMENS(standard),FANUC, KND, GSK (optional) | |||
| N.W | kg | 1700 | 2100 | 2300 | 3100 |
| Dimension | mm | 2100*1100*1700 2300*1500*1800 |
1900*1100*1700 | 2700*1700*1700 | 2600*1200*1700 (750mm) 2800*1200*1700 (1M) |
III. Company Information
Shandong Hunk Precision Machinery Co., Ltd. is a CNC machine tools company, located in the beautiful capitcal Jinan city, integrated with manufacturing, processing and sales. It was set up by the former Jinan Machine tools factory employees. It has a subsidiary corporation Jinan HANKUI International Trade Co., Ltd. The plant area is about 10,000 square meters. We have a number of R&D persons and technicians who have more than 20 years experience of machine tool design and assembly. We have mastered the advanced machine tool technology and were dedicating to service customers domestic and abroad and welcomed deeply.
 IV. Product Range of Hunk
(1) CNC Milling Machine
(2) CNC Vertical Machining Center
(3) CNC Turning Lathe
(4) Flat Bed CNC Turning Lathe
(5) CNC Horizontal Turning Lathe
(6) Slant Bed CNC Turning Lathe
(7) CNC Horizontal Machining Center
(8) Gantry Machining Center
(9) Pipe Threading CNC Lathe
(10) CNC Vertical Lathe
